"""2026-01-13
Tiles 01
Desenho de uma malha de formas que se transformam ciclicamente.
ericof.com|https://openprocessing.org/sketch/2757066
png
Sketch,py5,CreativeCoding
"""
from sketches.utils.draw import canvas
from sketches.utils.draw.cores.paletas import gera_paleta
from sketches.utils.helpers import sketches as helpers
import py5
sketch = helpers.info_for_sketch(__file__, __doc__)
shapes = []
cor_fundo = py5.color(0)
paleta = gera_paleta("Warhol", True)
def tiling():
c = 15
w = py5.width / c
step_i = py5.cos(py5.PI / 6)
step_j = py5.cos(py5.PI / 3) * 3
i = -1.5
while i < c:
j = -1
while j <= c:
x = i * w + w / 2
y = j * w + w / 2
shapes.append(Shape(x, y, w))
shapes.append(
Shape(
x + (w / 2) * py5.cos(py5.PI / 6),
y + (w * 1.5) * py5.cos(py5.PI / 3),
w,
)
)
j += step_j
i += step_i
class Shape:
def __init__(self, x, y, w):
self.x = x
self.y = y
self.w = w
self.current_w = w
self.shape_type = 0
dst = py5.dist(center_x, center_y, x, y)
max_dst = py5.sqrt((py5.width / 2) ** 2 + (py5.height / 2) ** 2)
self.timer = -int(py5.remap(dst, 0, max_dst, 100, 0))
self.t1 = 30
self.t2 = self.t1 + 30
self.t3 = self.t2 + 120
self.clr = py5.random_choice(paleta)
def show(self):
py5.push_matrix()
py5.translate(self.x, self.y)
py5.rotate(py5.PI / 6)
py5.fill(self.clr)
py5.no_stroke()
if self.shape_type == 0:
py5.begin_shape()
a = 0.0
step = py5.TAU / 6
while a < py5.TAU - 1e-9:
py5.vertex(
self.current_w * 0.5 * py5.cos(a), self.current_w * 0.5 * py5.sin(a)
)
a += step
py5.end_shape(py5.CLOSE)
elif self.shape_type == 1:
py5.circle(0, 0, self.current_w * 0.5)
elif self.shape_type == 2:
py5.rect(0, 0, self.current_w * 0.75, self.current_w * 0.9)
elif self.shape_type == 3:
py5.begin_shape()
a = 0.0
step = py5.TAU / 3
while a < py5.TAU - 1e-9:
py5.vertex(
self.current_w * 0.5 * py5.cos(a), self.current_w * 0.5 * py5.sin(a)
)
a += step
py5.end_shape(py5.CLOSE)
py5.no_stroke()
py5.fill("#00000050")
py5.pop_matrix()
def update(self):
if 0 < self.timer < self.t1:
nrm = py5.norm(self.timer, 0, self.t1 - 1)
self.current_w = py5.lerp(self.w, self.w * 0.2, nrm**3)
elif self.t1 < self.timer < self.t2:
nrm = py5.norm(self.timer, self.t1, self.t2 - 1)
self.current_w = py5.lerp(self.w * 0.2, self.w, nrm ** (1 / 3))
if self.timer == self.t1:
self.shape_type += 1
if self.shape_type == 4:
self.shape_type = 0
self.clr = py5.random_choice(paleta)
if self.timer > self.t3:
self.timer = 0
self.timer += 1
def run(self):
self.show()
self.update()
def setup():
global center_x, center_y
py5.size(*helpers.DIMENSOES.external, py5.P3D)
py5.background(cor_fundo)
py5.color_mode(py5.HSB, 360, 100, 100)
center_x, center_y = helpers.DIMENSOES.centro
tiling()
def draw():
py5.background("#020202")
for s in shapes:
s.run()
# Credits and go
canvas.sketch_frame(
sketch, cor_fundo, "large_transparent_white", "transparent_white"
)
def key_pressed():
key = py5.key
if key == " ":
save_and_close()
def save_and_close():
py5.no_loop()
canvas.save_sketch_image(sketch)
py5.exit_sketch()
if __name__ == "__main__":
py5.run_sketch()
